Magnetic resin shielded SMD power inductor.
Magnetic resin shielded inductor is produced under complete automation, designed with closed magnetic circuit, it has characteristics of low magnetic leakage and high anti-EMI ability. Shielded with magnetic resin, the buzz is reduced to a large degree. Rated current of this kind of inductor is around 20%-30% higher than it of ordinary inductors of similar sizes. Regarding practical application, metalizing electrodes directly on the ferrite core ensures a high machnical quality and durability. Besides, magnetic resin-shielded inductor is power efficient, and the miniature size greatly saves PCB area and space. It's generally applied to LED lighting, mobile phone, flat panel TV, blue-ray DVD, set top box, notebook and desktop computer, server, graphics card, navigation system, multimedia equipment, etc.
| Naming rules | Size and inductance range(common) | ||
| Eg: CSR5020T-6R8M | Size | Inductance range | |
| CSR | Magnetic resin shielded series | 2512 | 0.47~22uH |
| 5020 | Size(5.0mm*2.0mm) | 3015 | 1~150uH |
| T | Tape&Reel | 4018 | 0.47~220uH |
| 6R8 | Inductance(6.8uH) | 4030 | 0.68~680uH |
| M | Tolerance(20%) | 5020 | 0.56~200uH |
| 5040 | 0.22~680uH | ||
| 6045 | 0.47~680uH | ||
| 8040 | 0.82~470uH | ||
| 8065 | 0.68~680uH | ||
Click the button to open the catalog：
Product parameters in the catalog are for general choices. Should you not find proper parts, contact us for a further inquiry.
